FiberHome HG6145F User Manual

2 Product Introduction
Figure 2-2 Overall Outlook of the HG6145F
Interface and Button
Table 2-8 Interfaces and Buttons of the HG6145F
Interface and Button
Description
Function
WPS 2.4G/5G WPS button Enables or disables 2.4G/5G WPS.
WLAN 2.4G/5G WLAN button Enables or disables 2.4G/5G WLAN.
Phone
Telephone interface Connects to the user's telephone.
LAN1 to LAN4 Ethernet interface
Connects with the computer, IP router or IP set top box.
USB1, USB2
USB Host interface
Connects to the USB interface storage device.
Power Power interface
Connects with the power adapter.
On/Off Power switch
Turns on or off the power for the equipment.
Reset Reset button
Pressing down the button for more than 5 seconds to
restore the factory settings and reboot the equipment.
PON Fiber interface
Connects with optical fiber for uplink access.
Version: A 7
