FiberHome HG6145F User Manual

HG6145F GPON Optical Network Terminal Product Manual
Indicator LED Description
Indicator LEDs of the HG6145F are located on the front panel of the equipment.
Table 2-9 Indicator LEDs on the HG6145F
Indicator LEDs
Meaning
Color Status
Status Description
Power
Power status
indicator LED
Green
ON
The equipment is powered on.
OFF
The equipment is not powered on.
PON
Register status
indicator LED
Green
ON The ONT is activated.
Blinking The ONT is being activated.
OFF
Activation of the ONT is not yet started.
LOS
Optical signal status
indicator LED
Red
Blinking
The equipment has not received the optical
signal.
OFF
The equipment has received the optical
signal.
Internet
Broadband network
status indicator LED
Green
ON
Connection to the broadband network is
normal.
Blinking
Connection to the broadband network is
normal with data transmission.
OFF Not connected to the broadband network.
WLAN
2.4G/5G wireless
signal status
indicator LED
Green
ON The 2.4G/5G wireless interface is enabled.
Blinking
The 2.4G/5G wireless interface is transmitting
/ receiving data.
OFF The 2.4G/5G wireless interface is disabled.
WPS
2.4G/5G WPS status
indicator LED
Green
ON
The 2.4G/5G WPS is enabled, and the Wi-Fi
terminal has been connected to the ONT.
Blinking
The 2.4G/5G WPS is being used in
negotiation.
OFF
The 2.4G/5G WPS is not enabled, or the Wi-Fi
terminal is not connected to the ONT.
USB1, USB2
USB indicator LED Green
ON The USB is connected.
OFF The USB is not connected.
LAN1 to LAN4
Ethernet interface
status indicator LED
Green
ON
The interface is connected to the user terminal
and no data is transmitted.
Blinking The interface is transmitting / receiving data.
OFF
The interface is not connected to the user
terminal.
Phone
Phone port status
indicator LED
Green
ON
The port is registered in the softswitch system.
Blinking Service flow is found at the port.
8
Version: A
