Page 8
SWGII-4CC CARRIER SIDEWALL POWER VENTING KIT
Field Controls P/N 46205403, Carrier P/N KGASW03012SP
Kit Includes:
SWGII-4HD Sidewall Power Venter
CK-43CC Control Kit
Includes: 4" MG-1 Barometric Draft Control
Fan Proving Switch
Fixed post purge
For Use With The Following Carrier Furnace Models:
58UXT 58DXT 58UXV 58UHV 58TUA 58TMA
58WAV 58ZAV 58PAV 58RAV GB1AAV GB3AAV
For Use With The Following BDP Furnace Models:
330JAV 331JAV 333JAV 333BAV 330AAV 331AAV 395CAV
376CAV 383KAV 373LAV 480BAV 481BAV GB1AAV GB3AAV
For All Single-Furnace Systems:
Use one SWGII-4CC Kit for each furnace, and do not common-vent with other appliance(s). To
common-vent these furnaces with other appliances, use SWGII-4HD Kit with instruction P/N
46139100 and a CK Series Control Kit for each appliance.
For All Two-Stage furnaces:
When setting up a two-stage furnace, the furnace should be operating on HIGH-STAGE HEAT while
adjusting the sidewall power venter airflow adjustment damper, draft control, and proving switch.
VENTING INSTALLATION OPTIONS
FURNACE MODELS 4-in. dia. Type B-1 vent up
to 40 ft. long, up to 4
elbows, and 1 tee §
3-in. dia. Type B-1 vent up to 40 ft.
long, up to 4 elbows, and 1 tee §
Draft Safeguard
Switch Assembly
Two-Stage models
58UXT 330JAV
58DXT 331JAV
58UXV 333JAV
58UHV 333BAV
58TUA 330AAV
58TMA 331AAV
PERMITTED WITH ALL
GAS INPUT SIZES
A 5"-to-4" reducer is
required between furnace
and vent for inputs greater
than 105,000 Btu/hr.
PERMITTED WITH ALL GAS
INPUT SIZES ‡
A reducer is required between
furnace and vent for these inputs:
up through 105,000 Btu/hr 4"-to-3"
more than 105,000 Btu/hr 5"-to-3".
PERMITTED
WITH OR
WITHOUT THE
DRAFT
SAFEGUARD *
Single-Stage models
58WAV 395CAV
58ZAV 376CAV
58PAV 383KAV
58RAV 373LAV
GB1AAV 480BAV
GB3AAV 481BAV
PERMITTED WITH ALL
GAS INPUT SIZES
A 5"-to-4" reducer is
required between furnace
and vent for inputs greater
than 115,000 Btu/hr.
PERMITTED WITH GAS INPUTS
OF 88,000 Btu/hr AND LESS ‡
A 4"-to-3" reducer is required
between furnace and vent.
PERMITTED
ONLY WITH
THE DRAFT
SAFEGUARD †
