SM480VINT
1234
0000001234
SM380VINT
1234
0000001234
Metal shorting blocks are for
Rapid Rail™ Thermocouple
model JL3PC (sold separately)
Pipe Clamp Storage Arms
Removable rubber cover
Micro USB Port
Liquid
Line Port
Suction Line Port Valve
Liquid Line Port Valve
Vacuum Port Valve
Refrigerant Port Valve
(LOW)
(HIGH)
(VAC)
(REF)
Connect to a refrigerant
cylinder directly, or to
a recovery machine like
Fieldpiece model MR45
Refrigerant Port
Front View
11
