SUPPLEMENTARY OPERATING MANUAL 1
1-
1
GENERAL INTRODUCTION
Application Description
Application is a Armless Recoiler which uses linear analog position feedback for both the mandrel
and the sensor positioner. The mandrel to sensor positioner ratio is programmable. The SE-21A
sensor is used, which provides a reference channel for contamination compensation. An SBPC is
used for monitoring the system. The OSC-20 is used to provide oscillation of the web within the
proportional band of the sensor. External control via parallel input (X7) is required. When placed in
automatic mode, the sensor seeks the web edge. The sensor follows the web edge as long as
selected. Once Automatic is selected the sensor position and the mandrel position are recorded.
The sensor continues to follow the web edge and the mandrel then follows the sensor positioner. A
CDP-01-MHH with FifeNet firmware is required for this application.
Software Part Numbers
The software part numbers are located on the side of the CDP-01 housing. They include the Matrix
Setup no. (MS), State Machine no. (SM) and firmware version ( Dx ).
CDP version: CDP-01-H12 D1:565051-02x MS: 100333-02x Please quote these
D2:565052-02x SM: 100334-02x details with all inquiries.
D3:565052-02x FIFE USA
Connecting the System Components
The system components are to be connected according to the Cable Connection Diagram contained
in the documentation.
05-19-06 CDP-01 Figure Sheet 1-900
