9
fillrite.com | tuthill.com
INSTALLATION AND OPERATION MANUAL
Bold text indicates repairs that are not serviceable by the owner; please refer to our warranty policy on page 2 for further instructions.
* Repairs marked with an asterisk (*) will require Repair Kit #300KTF7794. This kit includes a replacement rotor and new vanes, as well as a number of other important seals and
components to complete the repair.
Troubleshooting (continued)
Symptom Cause Solution
Motor inoperative
1. No Power Check incoming power.
2. Switch failure Refer to warranty policy.
3. Motor failure Refer to warranty policy.
4. Thermal protector failure Refer to warranty policy.
5. Incorrect/loose wiring Check wiring.
Fluid leakage
1. Bad o-ring gasket Check all o-ring gaskets.
2. Dirty shaft seal Clean seal and seal cavity.
3. Bad shaft seal Replace seal.
4. Incompatible fluid Refer wetted parts list to fluid manufacturer (see page 7).
5. Loose fasteners Tighten fasteners.
Pump hums but
will not operate
1. Dirt in pump cavity Clean out pump cavity.
2. Motor failure Refer to warranty policy.
3. Broken rotor insert Remove all debris & replace insert.
Accessories
A wide variety of accessories are available to help you maximize the performance of your Fill-Rite pump. Listed below are the applicable available accessories for your specific product.
Please contact your authorized Fill-Rite distributor to purchase the accessories you need.
Part Number Description
F4010PM0 1" Filter (Particulate 10 micron)
F4030PM0 1" Filter (Particulate 30 micron)
700ACCF7017 1" Filter Head
FRPA125 Island Pedestal Mount Kit
KIT700AS Anti-Siphon Kit
FRH10012 1" Hose (12')
FRH10014 1" Hose (14')
FRH10020 1" Hose (20')
Part Number Description
FRHA10020 1" Arctic Duty Hose (20')
FRHMN100S 1" Nozzle, Manual Leaded Spout
N100DAU13G 1" Auto Shut Off Nozzle (Ultra High Flow Diesel)
N100DAU12G 1" Auto Shut Off Nozzle (High Flow Diesel)
FRNA100DAU00 1" Auto Shut Off Nozzle (Arctic Duty - Diesel)
S100H1315 1" Multi-Plane Swivel
B100F475 1" Breakaway
WH10012 1" Whip Hose
