PartTwo:ConnectingDigitalFillmastertoWaterPuricationSystem
Use the following steps to connect the dispenser to the Water Purication System. The same steps
are listed in Section 5 of the Water Purication System installation instructions (page XX-XX).
Tools Needed:
• Tube cutters
• Drill
Parts Needed:
• White ¼” tubing
• ZeroBac lter
• Shut-off valve
• ¼” elbow
• Mounting clip
• Screw
Connection Steps:
1. Take the end of the white ¼” tubing and cut two smaller pieces of tubing. The rst
should be about two inches long and the second should be ve or more inches long.
2. Attach a shut-off valve to the end of the white ¼” tubing coming from the “OUT”
port of the DI lter. Make sure the valve is in the off position (perpendicular to
tubing).
3. Attach the smaller piece of tubing between the other end of the shut-off valve and
the “IN” port of the ZeroBac lter.
4. Take the longer piece of cut tubing and attach the ¼” elbow to one end.
5. Attach the open end of the longer second piece of cut tubing to the open port of the
ZeroBac lter. Attach the end of the tubing with the ¼” elbow to the inlet of the
dispenser.
6. Use the drill to install a mounting clip on the wall to hold the ZeroBac lter in place
once you have determined where the lter will lie.
7. Continue to Part Three: Installing the Battery.
