Fimap IMx - Remove and clean Squeegee bar; Clean bowl filter cover

© Copyright A+D Supplies 2017 A+D Supplies, Marsh House, Brunel Road, Newton Abbot, Devon, TQ12 4PB www.adswsupplies.com
3. Remove and
clean Squeegee bar
4. Check hose 5. Clean bowl filter
cover
6. Check the floor
pad
Take the squeegee bar off
the machine by unscrewing
the two plastic nuts and
drawing the bar backwards
Disconnect the squeegee
hose.
Clean the squeegees
under running water
Refit squeegee bar
Check the squeegee hose.
If needed remove from
machine and flush through
with clean water.
Re-fit hose
Open the recovery tank
and remove the yellow
bowl filter cover and rinse
out.
Tip the machine back onto
the rear wheels.
With the machine switched
on, hold down the release
switch and then squeeze
the D handle once.
The Drive Board will
release
Cleaning After Use
