Fimap IMx - Charging Battery and Storage; Check the Battery charge level; Charge Battery

© Copyright A+D Supplies 2017 A+D Supplies, Marsh House, Brunel Road, Newton Abbot, Devon, TQ12 4PB www.adswsupplies.com
1. Check the Battery
charge level
2. Charge Battery
When the batteries are
fully charged and the green
light is showing on the
charger, switch off the
charger and unplug from
the machine.
Re-plug in the machine
main cable connector
IMPORTANT!
ONCE THE BATTERY
HAS STARTED
CHARGING IT MUST
NEVER BE DISTRUPTED
UNTIL THE GREEN LIGHT
SHOWS ON THE
CHARGER
PERMENANT DAMAGE
TO THE BATTERY WILL
OCCUR IF CHARGING IS
DISRUPTED
Turn the machine on and
check the battery level
Try not to charge the
battery if the level is over
50%
To charge the battery
unplug in the main cable
here.
Fit the charger plug in it’s
place, switch on the
charger
Charging Battery and Storage
