- 29 - English language
INDUCTION PLATES
A) Control panel: it is equipped with the control devices needed to operate the appliance
(see "Control descriptions").
B) Cook plate: it is made of pyroceram and is equipped with induction coils that generate
the heat required to process food products.
TECHNICAL SPECIFICATIONS
The table lists container material types.
Table 1: Technical appliance specifications
Description
Unit of
measure
PFD/27
PFD/35
Power kW 2,7 3,5
Power supply V/Ph/Hz 230V/1N/50Hz
Inductive surface diameter mm 140÷220
Appliance dimensions mm 325x370x105 343x440x120
Packaging dimensions mm 430x370x160 510x420x190
Net weight kg 5 8
Installation type Counter installation
Table 2: Container materials
Container material Induction operations
Steel Yes
Cast iron Yes
Enamelled plate Yes
Aluminium or brass No
Heat resistant glass No
Heat resistant ceramic or porcelain No
Wax paper No
