Fimar TR22/RS - Dismantling the Mincing Set; Recommendations for Use; End-Day Cleaning; Long Periods of Inactivity

OPERATION AND
CLEANING
3
Dismantling the mincer set
• Remove the hopper from the upper mouth.
• Turn the handwheel anti-clockwise.
• Extract
- the mincing plate;
- the blade;
- and the volute in sequence
• Screw off the mincer body-blocking knob and
extract mincer body.
• Perform operations in reverse order to
reassemble mincer group.
• Remove the hopper from the upper mouth.
• Turn the handwheel anti-clockwise.
• Extract
- the mincing plate;
- the blade;
- and the volute in sequence
• Screw off the mincer body-blocking knobs and
extract mincer body.
• Perform operations in reverse order to
reassemble mincer group.
INFORMATION: Prior to each work cycle ensure that the removable parts are properly fixed
to the machine.
Recommendations for use
The completely extractable mincing (only mod.TR22/TS-TR32/TN-AB22/AT) permits the user to place it in
refrigerators and other similar devices, even when it contains residual product. This feature makes it
possible to use the mincer at different times of the day without having to wash and clean the various
components after use, in conformity with hygiene laws currently in force.
End-of-day cleaning
• At the end of the working day remove the plug from the power socket.
• Clean thoroughly using neutral products.
• Wash the outer part of the machine using a damp sponge.
• Do not use steel wool or abrasive pads.
• Dismantle the mincer set and wash using suitable detergents in hot water or in the dishwasher.
Long periods of inactivity
If the machine is to be left idle for long periods of time, turn off the main wall switch, thoroughly clean the
machine and cover it with a sheet to protect it from dust.
