SPECIFICATIONS
1. AC LINE PROTECTION - A 100,000 ampere interrupting capacity AC line fuse provides instantaneous
protection from peak loads and fault currents. This line fuse is located inside the controller. A molded-
case, magnetic-trip circuit breaker (Option 1010) is available for Model 2601 Controllers, which provides
a manual disconnection to the controller, and also provides automatic instantaneous trip protection from a
peak load.
2. AUXILIARY CONTACT - A normally-open Form A relay contact, rated 5 ampere @115 VAC and 30
VDC, is available for external use. The relay energizes when a Run command is initiated, and de-energizes
when a Normal Stop command is initiated, the overload monitor trips, or the anti-restart circuit is acti-
vated.
3. CONTROL VOLTAGE - A transformer coupled 24 VDC power supply isolates all magnetic control
logic and operator controls from the AC power source for operator protection.
4. DIP SWITCH SETTINGS - A 7-position DIP Switch (S3) is used to program the controller for various
applications as shown in Table 13.
TABLE 13. DIP SWITCH S3 SETTINGS
SEGMENT
SEGMENT POSITION
DESCRIPTION
ON
(Closed)
OFF
(Open)
1
X Low voltage tachometer generator signal (8 VDC - 30 VDC)
X High voltage tachometer generator signal (31 VDC - 175 VDC)
2
X Armature feedback
X Tachometer feedback with armature feedback backup
3
X Armature feedback
X Tachometer feedback with armature feedback backup
4
X 4 mA - 20 mA input speed reference signal
X 0 - 5 VDC input speed reference signal
5
X
Enables the internal current limit circuit, adjustable with the CUR LMT
potentiometer.
X
Enables the use of an external current (torque) limit potentiometer (5K
ohm, 1/2W)
6
X Selects the MIN SPD potentiometer as a minimum speed adjustment
X
Selects the MIN SPD potentiometer as an offset adjustment for a 4 mA -
20 mA input speed reference signal
7
X
Enables anti-restart. Prevents the controller from restarting automati-
cally after an AC power interruption.
X Line starting. Disables anti-restart.
