Fincor 2600 Series User Manual

BOOK0795-F
1
SECTION I
GENERAL INFORMATION
INTRODUCTION
This manual contains installation, operation, and maintenance and repair instructions for Fincor Series 2600/
2610 Single-Phase Adjustable-Speed DC Motor Controllers. A parts list, list of options, ratings and specifications,
and drawings are also included.
GENERAL DESCRIPTION
Series 2600/2610 Controllers statically convert AC line power to regulated DC for adjustable-speed arma-
ture control of shunt-wound and permanent-magnet motors.
Series 2600/2610 Controllers comply with applicable standards established by the National Electrical Code
and NEMA for motor and industrial control equipment. The controllers are Underwriters Laboratories Listed (File
No. E60207) and CSA approved (File No. LR19781).
MODEL TYPES
TABLE 1. SERIES 2600 MODEL MATRIX
MODEL
FUNCTION CONFIGURATION
OPERATOR
CONTROLS
POWER
SOURCE
a
&
HP RANGE
a. Units are reconnectable
RUN-
STOP
b
b. No armature contactor
RUN-
STOP-
DB
c
c. Includes armature contactor
ARMATURE
SWITCH
REVERSE
b
ARMATURE
CONTACTOR
REVERSE
AND DB
c
OPEN
CHASSIS
ENCLOSED
LOCAL
INTEGRAL
REMOTE 115V 230V
2601 X X X
1/6 - 1 1/3 - 3
2601A X X X X
2601P0 X X X
2601P1 X X X
2601AP0 X X X X
2601AP1 X X X
2601AP3 X X X
2602 X X X
1/6 - 2 1/3 - 5
2602A X X X X
2602P0 X X X
2602P1 X X X
2602AP0 X X X X
2602AP1 X X X
2602AP3 X X X
