Periodically wipe the case with a damp cloth and detergent;
do not use abrasives or solvents. Open the clamp jaws and
wipe the magnetic pole pieces with a lightly oiled cloth. Do
not allow rust or corrosion to form on the pole pieces.
The serial number is stamped on the back of the unit. The
serial number should be used when ordering parts or
requesting service/calibration information.
7.2 Replaceable Parts
WHEN SERVICING THIS METER, USE ONLY THE
REPLACEMENT PARTS SPECIFIED.
Replaceable parts are
s
hown in Figure 3 and listed in
Table 2.
28 29
7.3 Calibration
This Meter should be calibrated annually. Regarding the
service/calibration informat
i
on on this Meter, contact the
nearest distributor of this Meter.
Figure 3. Replaceable Parts
Table 2. Replaceable Parts
ITEM DESCRIPTION PART
NUMBER Q’TY
1 Lens, LCD CL2 LENS 1
2 Cover, Rear CL2 CASE 1
3 Screw, Case (metric) CL2 SCRW 2
4 Battery, 9V CL1 BT09 1
5 User’s Manual CL3 MAN 1
6 Clip-on Holster C130 1
7 Test Lead Set TL34 1
