Measurement Limits:
AC Amperes : True-rms 0.3 to 700A
DC Amperes : 0.3 to 700A
AC Voltage : True-rms 0 to 750V
DC Voltage : 0 to 750V
Frequency : 0.5 to 9999Hz
Resistance : 0 to 4KΩ
Continuity Check : Beep at Approx. < 35Ω
in the 400Ω range
WARNING!
READ “ CLAMP-ON METER SAFETY” BEFORE USING
THIS METER.
1. Introduction
2. Clamp-on Meter Safety
3. Explanation of Controls and Indicators
4. Alignment Marks
5. How to Use this Meter
6. Applications of Measurement
7. Maintenance and Calibration
8. Technical Data and Specifications
This Meter is a handheld and battery operated True-RMS
Clamp-on Meter that is de
s
i
gned and tested according to
IEC Publ
i
cation 348, Safety Requirements for Electronic
Measuring Apparatus (Protection Class ll) and other safety
standards (see “Technical Data”).
This Meter combines the speed and versatility of a high
resolution analog disp
l
ay with the precision of a digital meter.
Contents
1
1. Introduction
