Features
•
4 digit display with enunciators.
•
Measures in FEET (ft) or METERS (m).
•
Measures COPPER (CU) or ALUMINUM (AL) wire.
•
User Select Mode.
•
Resistance range for milliohm measurements.
•
Automatic temperature compensation.
•
User calibration mode. Calibration standard included.
•
Sleep mode.
•
Easy to use.
WARNING:
MAKE SURE WIRE UNDER TEST IS NOT ENERGIZED.
NEVER APPLY VOLTAGE TO INPUTS.
NOTE:
Temperature affects accuracy of readings. Please see accuracy
specifications. For best results, allow the CLM33 to attain the same
ambient temperature as the wire under test. The length of time this will
take depends on the ambient temperature. Typically it will take 10 to 15
minutes for the CLM33 to attain equal ambient temperature.
2
Specifications
Measurement Range:
Overall range limit 0.1 to 30.00km
0.15mm
2
to 240mm
2
Due to the minimum and maximum resistance limits, specific wires
will have a range specific to that wire. Please refer to the following
table to determine the minimum and maximum length that can be
measured for specific gauge wires.
