Finn B-70 - Shredder Box and Feed Chute (Standard Trailer Model); Standard Trailer Model Parts List

LBB70-SS
16
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
SHREDDER BOX AND FEED CHUTE
(STANDARD TRAILER MODEL)
Ref. No. Part Number Description No. Req’d
1 031287 Shredder Box 1
2 031284 Shredder Box Cover 1
3 031158-04 Feed Chute Hinge Pin w/ Nuts 2
4 031157 Feed Chute 1
5 031158-05 Feed Chute Stop w/ Nuts 1
6 030898 Feed Chute Extension 1
7 031184-01 Upper Feed Chute Stand 1
8 031184-03 Lower Feed Chute Stand 1
9 FW71225 Snapper Pin 1
10 031096-01 Shredder Door 1
11 031096-04 Shredder Door Hinge Pin w/Nut 1
1
2
3
4
5
6
7
8
10
11
3
9
