LBB70-SS
21
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
TRAILER ASSEMBLY
Ref. No. Part No. Description No. Req’d.
1 031205 Platform Assembly 1
2 031183-01 Guard Rail-Right 1
3 031183-02 Guard Rail-Left 1
4 031189 Jack 1
5 031202 2” Ball Hitch Assembly 1
030482 2” Ball (Optional)
6 031196-01 Fender Assembly - Right 1
031196-02 Fender Assembly - Left 1
7 031167 Axle Assembly 1
031220 Axle Shim Plate 2
8 031221 Complete Hub Assembly 2
WL9103305 Grease Seal 2
WLLM68149 Bearing, Inner Cone 2
WLL68111 Inner Cup 2
WL9080607 Hub/Drum 2
WLL44610 Outer Cup 2
WLL44649 Bearing, Outer Cup 2
WL90509 Spindle Washer 2
WL90601 Spindle Nut 2
WL91901 Cotter Pin 2
WL92102 Grease Cap 2
WL9251510 Wheel Stud 2
WL90608 Wheel Nut 2
031222 Right Brake Assembly 1
031223 Left Brake Assembly 1
9 031187 Wheel 2
031188 Tire 2
031179 Safety Chain 2
031180 Clevis Grab Hook 2
031181 Chain Connecting Link 2
10 031269 Bumper (Not Shown) 1
