LBB70-SS
25
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
POWER TAKE OFF ASSEMBLY
Ref. No. Part No. Description No Req'd
1 TD6939 Ring, Driving 1
2 TDM141A Piolt Bearing 1
3 TD2727 Nut 1
4 TDA1587 Lock washer 1
5 Clutch Assembly (includes: a thur f) 1
a Hub and Back Plate Assembly 1
a-1 TD110 D3 Pin, Plate 1
a-2 TDA3024 Hub Plate 1
b TDA2286 Clutch Release Spring 6
c TDA3507E Clutch Plate 1
d TD3951 Flotaing Plate 1
e Adjusting Yoke Assembly 1
e-1 TD2042 Adjusting Lock Pin 1
e-2 TD1382 Adjusting Lock Pin Spring 1
e-3 TD3206 Adjusting Yoke 1
e-4 TDB1535B Cotter Pin 4
e-5 TD2411 Finger Lever 4
e-6 TD110 D-3 Finger Lever Pin 4
f Sliding Sleeve Assembly 1
f-1 TDB1535B Cotter PIn 7
f-2 TDB1390 Slinding Sleeve 1
f-3 TDB1535B Cottor Pin 4
f-4 TD2968 Finger Lever Link 8
f-5 TDB1537B Finger Lever Link Pin 4
f-6 TDB1537C Link Pin 4
f-7 TDB1048D Internal Retaining Snap Ring 1
f-8 TDM1921 Ball Bearing 1
f-9 TDA4173A Collar 1
f-10 TDA2915L External Retaining Snap Ring 1
6 TDM2001E 5/16-18 x 5/8 Bolt 4
7 TDM2046L 5/16 Flat Washer 4
8 TDA1181 Bearing Retainer 1
9 TDA1002 Snap Ring, External 1
10 TDM177A Ball Bearing 1
11 TDM2032X Hub Key 1
12 TDA3026AK Shaft 1
13 TDM2032BE Shaft Key 1
14 Name Plate Gasket 1
15 TD1965D Name Plate 1
16 TDM2023F Screw 2
17 031219 Clutch Handle 1
