LBB70-SS
15
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
DISCHARGE ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 031247 Transition Assembly 1
2 031018-01 Elbow Bearing 3
3 031086 Transition Seal 1
031109 Seal Banding 32”
4 031243-08 Elbow Hinge Rod 1
5 031239 Elbow Assembly 1
6 031241 Elbow Handle 1
7 031242-03 Elbow Seal-Upper 2
8 031341 Seal Plate Assembly 1
8A 031338-01 Seal Plate Hinge 1
8B 031238-04 Seal Plate 1
8C 031338-08 Side Seal 2
8D 031338-07 Side Seal Retaining Strap 2
8E 031338-03 End Flap Seal Retaining Strap 1
8F 031338-04 End Flap Seal 1
9 031238-05 Hinge Seal 1
10 031240 Discharge Tube 1
11 031242-04 Elbow Seal-Lower 2
12 031242-07 Elbow Seal Retainer Strap 2
13 031243-01 Discharge Tube Hold Down Bracket 1
14 031243-04 Discharge Tube Hold Down Arm 1
15 031245 Snapper Pin 1
16 031243-07 Elbow Tensioning Rod 1
17 031258 Lever Nut 1
18 031338-09 Top Seal 1
19 031338-10 Top Seal Retaining Strap 1
20 031338-12 Side Elbow Seal 2
21 031338-11 Hinge Seal 1
