Finn EAGLE 244D - Main Arm Assembly

19
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
MAIN ARM ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 071264 Universal Face Plate Assembly 1
1A 071037-01 Locking Pin 2
1B 071114 Compression Spring 2
1C 071037-05 Locking Pin Boss 2
1D 071040 Roll Pin 2
1E 071265 Universal Face Plate 1
1F 021823 Grease Fitting 2
2 071127* Dump Cylinder 1
2A 071126P Cylinder Pin – Long 1
2B 071127P Cylinder Pin – Short 1
3 071177 Main Arm 1
3A 071122 Bronze Bushing 2
3B 071123 Bronze Bushing 2
3C 071292 Bronze Bushing 2
4 071126* Main Arm Cylinder 2
4A 071126P Cylinder Pin – Long 2
5 071113-01 Long Pivot Pin 4
5A 080653 Grease Fitting 4
6 071113-02 Short Pivot Pin 2
6A 080653 Grease Fitting 2
7 023684 Hose Clamp 4
8 071281 Tubing Clamp 2
071282 Tubing Clamp Cover 2
9 071146 Bronze Thrust Washer 4
10 071121 Main Arm Cushion Strap 1
11 X0412 1/4-20 UNC Hex Head Bolt x 3/4”Lg.
12 W04L 1/4” Lock Washer
13 W04F 1/4” Flat Washer
14 X0420 1/4-20 UNC Hex Head Bolt x 1-1/4” Lg.
15 W05 5/16" Flat Washer
16 W05L 5/16" Lock Washer
17 X0512 5/16-18 UNC Hex Head Bolt x 3/4" Lg.
* 071215 Cylinder Repair Kit
