21
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
LOOSE PARTS ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 F250-0015-03 Fender-Right Hand Side 1
2 FW71225 Snapper Pin 2
3 071155 Cylinder Lock 1
4 F250-0062 Lower Engine Cover 1
5 071106-05 Door Hinge 1
6 F250-0057 Oil Cooler Guard 1
7 071048 Cooler Panel Latch – Right Hand Side 1
8 F250-0060 Oil Cooler Panel 1
190044 1/8 x 1 Foam Gasket 36”
9 071049 Cooler Panel Latch – Left Hand Side 1
10 071105 Fuel Tank – Right Hand Side 1
11 007914 Fuel Tank Cap 2
12 071008 Control Valve Cover Plate 1
13 071102 Foam Handle Grip 2x6"
14 F250-0054-02 Control Panel 1
15 071248 Step 1
16 071305 Platform 1
190017 6" Safety Walk 2x18"
17 007914 Fuel Tank Cap 2
18 071104 Fuel Tank – Left Hand Side 1
19 F250-0015-01 Fender-Left Hand Side 1
20 F250-0073 Access Panel 1
21 071188 Filler Breather Cap w/Dipstick 1
22 071181 Battery 1
23 071189 Battery Holddown Clamp 1
24 071241 Lower Louver Guard 1
071284-05 Exhaust Mount 1
F250-0070 Radiator Shroud 1
071289-05 Radaitor Door 1
F250-0072-02 Fuel Line Guard-Right Hand Side 1
F250-0072-01 Fuel Line Guard-Left Hand Side 1
