WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
HYDRAULIC SCHEMATIC: Suction, Return & Propel
Ref. No. Part Number Description No. Req’d
1 071000 Main Control Valve 1
071166-01 Propel "T" Handles 2
071166-02 Cylinder Control "T" Handles 2
2 071001 Hydraulic Pump 1
3 071238 Hydraulic Wheel Motor 4
4 071239 Over Center Valve 2
5 071275 Hydraulic Oil Cooler 1
6 021617 Return Filter Assembly 1
021618 Return Filter Element 1
9 004618 Suction Strainer 1
10 FW71591 90° Adapter Elbow 2
11 071258 Suction Hose 1
12 012087 Straight Adapter 1
13 071125 45° Adapter Elbow 1
14 071075 Valve Inlet Hose 1
15 023621 90° Adapter Elbow 1
16 012044 Pressure Gauge 1
17 FW71892 Street Elbow 1
18 071227 Straight Adapter Union 1
19 055231 Straight Adapter 4
20 085189 45° Adapter Elbow 2
21 FW71636 90° Adapter Elbow 2
22 071262 Lower Valve Hose 2
23 071263 Upper Valve Hose 2
24 FW71448 45° Adapter Elbow 8
25 071260 Rear Motor Hose 2
26 085014 Straight Adapter 8
27 071259 Motor Connector Hose 2
28 071261 Front Motor Hose 2
29 FW75148 Straight Adapter 1
30 071157 Valve Outlet Hose 1
31 080649 45° Adapter Elbow 1
32 023616 Straight Adapter 1
33 008543 90° Straight Adapter 2
34 071156 Cooler Return Hose 1
35 005548 90° Adapter Elbow 1
47 071280 Straight Adapter 1
071006 Hydraulic Reservoir Drain Plug 1
