WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
HYDRAULIC SCHEMATIC: Attachments
Ref. No. Part Number Description No. Req’d
1 071000 Main Control Valve 1
071166-01 Propel "T" Handles 2
071166-02 Cylinder Control "T" Handles 2
50 055232 Straight Adapter 4
51 071279 Attachment Hose-Long 1
52 071243 Attachment Hose-Short 3
53 031411 Straight Bulkhead Fitting 6
54 FW71870 90° Swivel Adapter Elbow 2
55 071093 90° Bulkhead Fitting 2
56 071082 Attachment Hose 4
57 071072 Right Outer Attachment Tube 1
58 071070 Right Inner Attachment Tube 1
59 071092 Straight Swivel Adapter 4
60 071088 Female Quick Disconnect 2
071135 Quick Disconnect Plug 2
61 071089 Male Quick Disconnect 2
071134 Quick Disconnect Cap 2
62 071071 Left Inner Attachment Tube 1
63 071073 Left Outer Attachment Tube 1
