Finn EAGLE 250 - Main Arm Assembly

LBSS250-SM Rev A
19
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
MAIN ARM ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 071111 Universal Face Plate Assembly 1
1A 071037-01 Locking Pin 2
1B 071114 Compression Spring 2
1C 071037-05 Locking Pin Boss 2
1D 071040 Roll Pin 2
1E 071050 Universal Face Plate 1
1F 021823 Grease Fitting 2
2 071127* Dump Cylinder 1
2A 071126P Cylinder Pin – Long 1
2B 071127P Cylinder Pin – Short 1
3 071177 Main Arm 1
3A 071122 Bronze Bushing 2
3B 071123 Bronze Bushing 2
3C 071118-05 Bronze Bushing 2
4 071126* Main Arm Cylinder 2
4A 071126P Cylinder Pin – Long 2
5 071113-01 Long Pivot Pin 4
5A 080653 Grease Fitting 4
6 071113-02 Short Pivot Pin 2
6A 080653 Grease Fitting 2
7 008422 Hose Clamp 4
8 071106-08 Tubing Clamp 2
9 071146 Bronze Thrust Washer 4
10 X0412 1/4-20 UNC Hex Head Bolt x 3/4”Lg. 10
11 W04L 1/4” Lock Washer 12
12 W04F 1/4” Flat Washer 10
13 X0420 1/4-20 UNC Hex Head Bolt x 1-1/4” Lg. 2
* 071215 Cylinder Repair Kit
