LBSS250-SM Rev A
25
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
POWER SYSTEM
Ref. No. Part Number Description No. Req’d
1 071007 25 HP Kohler Engine 1
KL1205001 Oil Filter 1
KL2408303 Air Cleaner Element 1
KL2408305 Pre-Cleaner Element 1
KL2406807 Muffler 1
071209-01 Upper Tail Pipe 1
071209-02 Lower Tail Pipe 1
031421 Exhaust Pipe Clamp 2
F250-0032 Tail Pipe Bracket 1
035026 Tini Tachometer 1
071099 Throttle Cable 1
071098 Choke Cable 1
071181 Battery 1
031031 Positive "+" Battery Cable 1
000241 Ground Strap 1
2 Y05 5/16-18 Hex Nut 8
3 W05L 5/16 Lock Washer 8
4 W05F 5/16 Flat Washer 8
5 X0512 5/16-18 Hex Head Bolt x 3/4 Lg. 4
6 F250-0034 Engine Mounting Plate 1
7 X0528 5/16-18 Hex Head Bolt x 1-3/4 lg. 4
8 071144 Engine Wiring Assembly 1
9 KL2515506 Female Engine Plug 1
KL4815501 Male Engine Plug 1
170077 Male Terminals 4
170078 Female Terminals 4
10 080654 Ignition Switch 1
11 071181 Battery 1
12 007470 Street Elbow- 1/4 2
13 007476 Hose Barb Adapter- 1/4 2
14 190034 1/4 Fuel Line Hose 5”
010321 Fuel Line Clamp 2
15 071090 Hose Barb Tee- 1/4 1
16 190034 1/4 Fuel Line Hose 12”
010321 Fuel Line Clamp 2
17 KL2505002 In-line Fuel Filter 1
18 190334 1/4 Fuel Line Hose 29”
010321 Fuel Line Clamp 2
19 071220 Connector- 1/4 2
To Next Page
