WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
HYDRAULIC SCHEMATIC: Cylinders
Ref. No. Part Number Description No. Req’d
1 071000 Main Control Valve 1
071166-01 Propel "T" Handles 2
071166-02 Cylinder Control "T" Handles 2
7 071126* Main Arm Lift Cylinder 2
8 071127* Bucket Dump/Curl Cylinder 1
19 055231 Straight Adapter 4
32 FW71619 Tee 2
45 FW71636 90° Swivel Adapter Elbow 6
46 071194 Bucket Curl Tube – Valve 1
47 071195 Bucket Dump Tube – Valve 1
48 071201 Main Arm Raise Hose 2
49 071200 Main Arm Lower Hose 2
50 071191 Arm Raise/Lower Extension Tube 2
51 071193 Right-Hand Raise Lower Tube 2
52 071192 Left-Hand Raise Lower Tube 2
53 071094 90° Bulkhead Fitting 2
54 FW71448 90° Swivel Adapter Elbow 6
55 071068 Left Cylinder Tube 1
56 071069 Right Cylinder Tube 1
57 071169 90° Adapter Elbow 2
58 071083 Bucket Dump Hose 1
59 071084 Bucket Curl Hose 1
* 071215 Cylinder Repair Kit
