LBSS250-SM Rev A
31
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
HYDRAULIC SCHEMATIC: Attachments
Ref. No. Part Number Description No. Req’d
1 071000 Main Control Valve 1
071166-01 Propel "T" Handles 2
071166-02 Cylinder Control "T" Handles 2
60 055232 Straight Adapter 4
61 071051 Right Top Attachment Tube 1
62 071052 Right Bottom Attachment Tube 1
63 031411 Straight Bulkhead Fitting 6
64 FW71870 90° Swivel Adapter Elbow 2
65 071093 90° Bulkhead Fitting 2
66 071082 Attachment Hose 4
68 071072 Right Outer Attachment Tube 1
69 071070 Right Inner Attachment Tube 1
70 071092 Straight Swivel Adapter 4
71 071088 Female Quick Disconnect 2
071135 Quick Disconnect Plug 2
72 071089 Male Quick Disconnect 2
071134 Quick Disconnect Cap 2
73 071064 Left Top Attachment Tube 1
74 071065 Left Bottom Attachment Tube 1
75 071071 Left Inner Attachment Tube 1
76 071073 Left Outer Attachment Tube 1
To Next Page
