Instructions, Maintenance and Service Manual ULTRAFREEZER Series
4
3.1 Controller
Type
SL9002 – Slimline, version 1.04
Case
Aluminium built-in profile
Dimensions
200 * 72 * 30 mm (lxhxd)
Hole in the panel
min. 173 * 66 mm (bxh)
Front
Polycarbonate (IP-44)
Display
4-digit digital display
Connections
RS485 powered by 2x twisted-pair secured
min. 0,5 mm²
Operating temperature
-20°C/ +50°C
Storage temperature
-20°C/ +60°C
Operating humidity
10% / +90 % RH not condensing
Accuracy
± 0,5 % of the range
Status leds
COOL = relay cooling on
BACKUP = CO
2
backup cooling on
PRG. = PRG active
CODE = CODE active
Alarm leds
LOW BATT = battery empty
TEMP HIGH = warm temperature alarm
TEMP LOW = cold temperature alarm
Buttons
POWER ON/OFF = on/off button
▲= value increasing button
▼ = value decreasing button
PRG = program button with led
CODE = access code button with led
SETP. = set point button
BATT. = battery state button
Buzzer
Built-in buzzer for alarm
