FIOCCHETTI ULTRAFREEZER - Water-Cooled Condenser

Instructions, Maintenance and Service Manual ULTRAFREEZER Series
6
4. WATER COOLED CONDENSER (optional)
Water-cooled condenser system
Pressure pressostat (2) Water in- & outlet (1)
Cool technical diagram
freezer with water-cooled
condenser
Example back of upright
freezer, water-cooled
condenser, CO
2
emergency
cooling system (optional)
Fixation points
spacers
Water pressure valve
5
(5)(5) valvedruk
ventiel (5)
Water valve (3)
Condenser (6)
Inlet (4)
Outlet (1)
Inlet (4)
Uitlet (1)
