10-G Combi Control Panel Description
10
SPARE PARTS-BOILER
ITEM COMPONENT PART No. Qty
No. per boiler
32 Control panel back FC 03129 1
32a Control panel front FC 03130 1
32b Control panel top FC 03131 1
Timer bracket FC 03132 1
Timer blank FC 03133 1
33 Pressure Gauge FC 03134 1
33a Bracket for pressure gauge FC 03135 1
33b Nut for pressure gauge FC 03136 1
34 Timer FC 03137 2
35 Green neon light indicator FC 03138 2
35a Orange neon light indicator FC 03139 1
35b Red neon light indicator FC 03140 1
36 Green Light Bulb FC 03141 G 2
36a Orange Light Bulb FC 03141 O 1
36b Red Light Bulb FC 03141 R 1
37 4 Pin Socket FC 03142 2
37a 4 Pin Plug FC 03143 2
38 Wiring Strip connector FC 03144 1
38a Timer two piece wiring strip connector FC 03145 1
39 Cable Gland FC 03156 5
40 Relay base FC 03147 1
41 Relay FC 03148 1
42 Control stat eyebrow knob FC 03149 1
43 Control stat chrome bezel. FC 03150 1
44 Control stat FC 03151 1
45 Limit Stat FC 03152 1
46 Early alert stat FC 03153 1
47 Over run stat FC 03154 1
48 Relay tank stat FC 03155 1
