2
TECHNICAL SPECIFICATION
8
2-E&F Riello Burner Specification
Burner Description
One stage kerosene and oil burner.
In case of BF applications the intake air temperature must not be over 70C
The burner meets protection level of IP 40, EN 60529.
Burnerwith CE marking in conformity with EEC directives: EMC 89/336/EEC,
Low Voltage 73/23/EEC, Machines 98/37/EEC and Efficiency 92/42/EEC.
7. Pump pressure adjustment screw
8. Pressure gauge port
9. Photoresistance
1. Pump
2. Control-box
3. Reset button with lock-out lamp
4. Flange with insulating gasket
5. Air damper adjustment screw
6. Snorkel (BF)
Burner Equipment
Flange with insulating gasket............. No.1
Screw and nut for flange................... No.1
Grill (CF Application)........................ No.1
Bolts for flange to be fixed to boiler..No.4
Hexagonal Key................................... No.1
Screw of by-pass pump..................... No.1
Flexible oil pipe with nipple.............. No.1
