Fireboy- Xintex ESC Series User Manual

4
Part Number 18002, G, 09/24/2019
Specification Continued
System Specifications (ESC-0842-04D)
Operating Voltage: 9-32 VDC
Maximum Current Draw: 188mA @ 12 VDC
Operating Temperature: 22°F (-6°C) to 158°F (70°C)
Circuits: (2) 30 Amp, (4) 10 Amp, (2) 2 Amp
System Specifications (ESC-0860-04D)
Operating Voltage: 9-32 VDC
Maximum Current Draw: 188mA @ 12 VDC
Operating Temperature: 22°F (-6°C) to 158°F (70°C)
Circuits: (2) 30 Amp, (6) 10 Amp
System Specifications (ESC-1044-04D)
Operating Voltage: 9-32 VDC
Maximum Current Draw: 188mA @ 12 VDC
Operating Temperature: 22°F (-6°C) to 158°F (70°C)
Circuits: (2) 30 Amp, (4) 10 Amp, (4) 2 Amp
System Specifications (ESC-1062-04D)
Operating Voltage: 9-32 VDC
Maximum Current Draw: 188mA @ 12 VDC
Operating Temperature: 22°F (-6°C) to 158°F (70°C)
Circuits: (2) 30 Amp, (6) 10 Amp, (2) 2 Amp
System Specifications (ESC-1080-04D)
Operating Voltage: 9-32 VDC
Maximum Current Draw: 188mA @ 12 VDC
Operating Temperature: 22°F (-6°C) to 158°F (70°C)
Circuits: (2) 30 Amp, (8) 10 Amp
All above Current Draws represent a single Helm Display Unit.
Add an additional 25mA when using a second Helm Display Station.
