FIREtec FTEN1 - Front Panel Indicators and Controls; Front Panel Indicators; Zone and Alarm Disable

FRONT PANEL INDICATORS- show the
following:-
1.
GENERAL FIRE > red led – illuminates during a
fire or evacuation condition.
2. ZONES 1- 4 FIRE > red led’s - Illuminate when a
fire occurs on the relevant zone. The GENERAL
FIRE led will also be illuminated at the same time.
The fire led will flash during Walktest condition.
3.
GENERAL FAULT> yellow led - illuminates when
any a fault with the panel has occurred. The
specific FAULT led is flashed, or if no other FAULT
led is on, this indicates an auxiliary fuse failure.
4. ZONES 1-4 FAULT > yellow led’s – Flashes the
relevant zone led during a fault condition but is
illuminated to indicate a zone that is disabled or
is in Walktest. When in the Walktest menu the
appropriate led flashes quickly.
5.
SUPPLY > green led - Illuminated all the time.
6.
SUPPLY FAULT > yellow led – Flashes indicating
a power supply fault has occurred. Check mains
and battery connections as well as pcb fuses.
7. DISABLED > yellow led - illuminates when a fire
zone has been isolated, along with the relevant
zone fault led on steady.
8.
ALARM FAULT/DISABLED > yellow led –
Flashes when the panel detects a fault in the
sounder wiring. Common fault also illuminated. Is
illuminated when the alarms are disabled along
with the disabled led.
9.
TEST > yellow led - illuminates when the panel
is set to walktest mode.
10.
SYSTEM FAULT > yellow led - illuminates
if the panel has been restarted by the
supervisory circuit or is flashed if a
corruption of the software in the
microcontroller has been detected.
11.
ALARM SILENCED > yellow led –
Illuminates when the sounders on the
alarm circuits have been switched off
during a fire/evacuation – The alarm
condition still remains.
12.
EARTH FAULT > yellow led – flashes if a fault
with the earthing of the system has occurred.
4. DISABLE - If a fault occurs or work is being
carried out on a zone or alarm circuit, it is
possible to disable the zone(s) and alarm circuit
from the system without affecting the other
zones. If a zone or alarm is disabled, the
DISABLED led and the FAULT led(s) of the
corresponding zone(s) or alarm will be lit.
TO DISABLE A ZONE OR ALARM
Enter user code 5344. Press 4 – DISABLE. The
FAULT led of zone 1 (if it is not in Walktest)
flashes quickly.
Press 3 to advance to next zone/alarm
OR
Press 4 to disable the appropriate zone or
alarm. This causes the FAULT led of the selected
zone/alarm to be illuminated – showing that it is
disabled along with the DISABLE led being
illuminated.
Press 5 To exit from this menu.
TO RE-ENABLE DISABLED ZONES OR ALARMS
Enter user code 5344. Press 4 – DISABLE. The
FAULT led of zone 1 flashes quickly.
Press 3 to advance to appropriate zone. Press 4
to re-enable a zone/alarm. If a zone/alarm is
being re-enabled, the illuminated FAULT led of
the re-enabled zone is cleared and moves to the
next zone/alarm.
Press 5 to exit from this menu.
