INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND
USE Rev−12
PMKIE−DIMU−GB−12
25
GB
INDIRECT TILTING PANS, ELECTRIC TYPE
ˆPMKIE100˜ ˆPMKIE150˜ ˆPMKIE200˜ ˆPMKIE300˜ ˆPMKIE500˜
7 FIGURES AND DETAILS
7.1 LAYOUT CONNECTIONS PMKIE
LEGEND:
E Electrical connection 1 Vat water feed tap
Q Equipotential clamp 2 Jacket level tap
A Hot water connection 3 Security group
B Cold water connection OPTIONAL
4 Cooking vat drainage tap
