GENERAL OPERATION
The ED510 displays current burner status, first out annunciation in the event of a lockout condition,
historical burner information, detailed lockout information of the last six (6) lockout conditions,
diagnostic messages, and the ability to program messages associated with the E300 Expansion Mod-
ule.
Depending on the information being displayed, data is displayed on the ED510 screen in the follow-
ing locations.
ED510 MESSAGES (as used with Flame-Monitor)
RUN MESSAGES
The operating control of the FLAME-MONITOR (terminals L1-13) is open.
Firing rate motor sent to high fire (term. 10-X made), purge timing displayed
upper right hand corner.
Firing rate motor sent to low fire (term. 10-12 made), purge timing displayed in
upper right hand corner.
PTFI timing started. Pilot not proven yet. PTFI timing displayed in upper right
hand corner.
PURGE 00:05
STARTING BURNER
OPERATING STATUS
(Standby, Purge, PTFI,
Auto, etc.)
ADDITIONAL INFORMATION
(Flame Signal Strength, Cause of current Lockout, etc.) OR
BURNER HISTORY (SCRL key required)
(Burner Cycles, Burner Lockouts, etc.) OR
SUB-MENU HEADINGS (SCRL and MODE keys required)
(Lockout History, Program Setup, etc.
ON OPERATING STATUS
TIMING
(During Purge or PTFI) OR
FLAME SIGNAL STRENGTH
(During PTFI, MTFI, or Auto)
ARROW displayed when
MODE key is required to
access sub-menus
(Lockout, History, Program
Setup, etc.)
The EP(D) and MicroM programmers update the messages to the ED510 display at least
once every 8 seconds. If the ED510 display does not receive information from the EP(D)
programmer within 10 seconds the ED510 will display:
This can be the result of a defective connection between the programmer and display,
defective cable, defective drivers in the programmer or display, or an electrical noise tran-
sient causing the EP(D) or MicroM programmers to cease communication.
Removing and restoring power should be executed to recover proper operation. Refer to
bulletin SN-100 for recommended techniques for display installation.
FIREYE ED510
WAITING FOR DATA
STANDBY
L1-13 OPEN
PURGE 00:05
HIGH FIRE PURGE
PURGE 00:35
LOW FIRE PURGE
PTFI 00:02
IGNITION TIMING
