CAUTION: To prevent shock hazard, remove power from the system wiring base before
proceeding. Remove control from the wiring base before proceeding.
The EP programmer modules are used with the Fireye EB700 and E110 chassis. They are installed in
the chassis by inserting the EP programmer module into the second slot on the control. This slot is
marked “Programmer Module” on the side of the chassis. Refer to bulletin E-1101 for complete sys-
tem information.
The programmer module is designed to fit only in the proper slot. It cannot be snapped into place if
inserted in the wrong location. DO NOT FORCE THEM.
An amplifier module, display module ED510 (ED500 is obsolete), flame scanner, and wiring base
are also required for the FLAME-MONITOR control.
All programmers with an Engineering code of 28 or later (e.g. 9414-28) are compatible with both the
ED500 and ED510 display modules. See “Programmer and Display Module Compatibility” later in
this document. The Engineering code is located on the back side of the board in the lower right hand
corner. The EP163 programmer requires the ED510 display for initial configuration programming.
%4463:%07
Underwriters Laboratories Inc.:
MCCZ File MP 1537
Controls, Primary Safety - Listed
MCCZ2 File MP1537
Controls, Primary Safety - Component
MCCZ7 File MP1537
Controls, Primary Safety Certified for Canada
MCCZ8 file MP1537
Controls, Primary Safety Certified for Canada - Component
ACCEPTABLE BY: INDUSTRIAL RISK INSURERS (I.R.I.)
FACTORY MUTUAL (FM) APPROVED
WARNING: This equipment generates, uses and can radiate radio frequency energy, and if not
installed and used in accordance with the instruction manual, may cause interference to radio
communications. It has been tested and found to comply with the limits for a Class A computing
device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable
protection against such interference when operated in a commercial environment. Operation of
this equipment in a residential area is likely to cause interference, in which case the user, at his
own expense, will be required to take whatever measures may be required to correct the interfer-
ence.
