Firman T07571 - T07571 Portable Generator Part List; Engine and Frame Parts List; Fuel and Control System Parts List; Electrical Components and Accessories Parts List

Parts Diagrams - Parts Lists - Wiring Diagram
English
35
Customer Service: 1-844-FIRMAN1
T07571 Portable Generator
NO.
Part Number
Description
Qty.
77
357713569
Screw&washer Assy M5×10
2
78
336713578
Nut M5
3
79
357713555
Bolt,bend Hook
2
80
357713556
Battery Red Cable +
1
81
336713842
Black Boot
1
82
336713693
Battery cable(Female 180mm)
1
83
357713531
Nut M10
2
84
357713532
Isolator 2
1
85
357713533
Isolator 1
1
86
357713585
Motor Mount
2
87
336713559
Flange. Bolt M8×16
4
88
357713538
Support Leg
1
89
336713557
Rubber, Support
2
90
336713561
Flange Bolt M6×25
4
91
336713514
Ground Wire
1
92
336713516
External Star Washer Ø6
1
93
336713601
Receptacle L14-30R
1
94
336713817
Control Module
1
95
375713001
Double Pole Circuit Breaker Amp 31A
1
96
336713819
Tapping Screw St2.9×19
2
97
336713820
Tapping Screw St2.9×32
1
98
336713821
Micro Switch 1
1
99
336713822
Micro Switch 2
2
100
336713824
Fuel Valve
1
101
375413002
Main Regulator Assy.
1
102
336713826
LPG Inlet Cover
1
103
336713816
Screw M4×12
1
104
336713815
Main Fuel Selector Switch
1
105
336713827
Electric Start Switch
1
106
336713828
Indicator Light
1
107
357713586
Multi Meter
1
108
336713574
Outlet Cover TT-30R/14-50R
1
109
336713573
Outlet Cover L5-30R
2
110
357713541
Outlet Cover 5-20R GFCI
1
111
380713512
Bolt M6×22
1
112
380713515
Nut M6
2
113
380713001
Screw&Washer Assy M4×20
2
114
336713569
Screw&washer Assy M4×8
10
115
330713582
Screw&washer Assy M4×14
6
116
380713552
Control Panel
1
117
380713518
Receptacle 14-50R
1
118
336713568
Nut M4
8
119
357713588
5-20R Duplex GFCI
1
120
336713526
Double Pole Circuit Breaker Amp 30A
1
121
336713585
Circuit Breaker Amp 20A
1
122
336713565
Screw M5×14
4
123
336713818
Charger
1
124
336713583
Receptacle L5-30R
1
125
380713555
Control Box
1
126
357713545
Grommet
1
127
357713546
Sleeve
1
128
357713548
Grommet
1
129
380713547
Metal Clamp
4
130
375723001
NG Hose
2
131
380713002
Screw&washer Assy M5×10
2
132
380713550
LPG/NG Selector Switch
1
133
380713003
Flange Bolt M6×6
2
134
357713598
Waterproof Cover
2
135
336713643
VF Protection Module
1
136
330713502
Screw M5×20
1
137
336713590
Cotter Pin, Handle
2
138
336713844
Washer Ø8
2
139
357713596
Axle Pin, Handle
2
140
357713597
Handle
1
141
336713841
Red Boot
1
142
336713611
Boot,starter
1
143
375413001
Control Panel Assy.
1
144
357413509
Wheel Kit
1
145
380413510
Rotor And Stator Set
1
146
357413503
Spark Arrestor Kit
1
147
357413506
Support Leg Assembly
1
148
336713691
Hose Holder
1
149
380413512
LPG-NG Selector switch assembly
1
150
380713542
Screw&washer Assy M3×6
4
151
380713562
Screw&washer Assy M5×8
4
152
357713607
Battery cable(Male 180mm)
1
153
360417010
Power Cord Holder
1
154
360457024
Short Power Cord
1
155
380727001
Cover
1
156
336713834
Regulator/Hose Assy.
1
NO.
Part Number
Description
Qty.
1
380713556
FIRMAN 439cc Tri-fuel Engine
1
2
357713501
Rubber Cap B
1
3
336713528
Flange Bolt M6×8
1
4
357713573
Generator Wind Shield
1
5
380713544
Rotor Assy
1
6
380713545
Stator Assy
1
7
380713557
Stator Cover
1
8
357713506
Generator End Cover
1
9
357713507
Carbon Brush Assembly
1
10
336713525
Carbon Brush Holder
1
11
336713524
Bolt &washer Assemblies
1
12
380713504
AVR
1
13
336713519
Flange Bolt M5×16
2
14
336713523
Terminal Block
1
15
336713520
Bolt M5×16
2
16
336713522
Ground Wire
1
17
357713509
Generator End Cover Cap
1
18
336713507
Flange Bolt M5×12
3
19
380713506
Flange Bolt M6×200
4
20
336713512
Lock Washer Ø6
8
21
336713513
Washer Ø6
4
22
336713577
Nut M5
2
23
380713507
Side Cover Bolt M5×229
2
24
357713511
Lock Washer Ø5
2
25
380713508
Flange Bolt M10×285
1
26
357713513
Lock Washer Ø10
1
27
357713514
Washer Ø10
5
28
336713531
Flange Bolt M8×20
4
29
357713515
Holder, Muff
1
30
336713515
Flange Bolt M6×12
19
31
357713516
Muffler Fixed Plate A
1
32
336713538
Screw&washer Assy M5×14
2
33
357713517
Holder, Spark Arrester
1
34
336713536
Arrester, Spark
1
35
357713518
Muffler Fixed Plate B
1
36
336713534
Nut M8
2
37
336713509
Lock Washer Ø8
2
38
336713533
Flat Washer Ø8
2
39
357713520
Gskt., Ext.
1
40
375413004
Muff.,Assy.
1
41
357713523
Muffler Fixed Plate C
1
42
336713517
Nut M6
4
43
357713577
Air Filter Bracket
1
44
357713524
Rubber Cap A
1
45
336713542
Grommet, Fuel Tank
4
46
336713543
Washer Tank Buffer
4
47
336713544
Flange Bolt M6×20
4
48
357713578
Fuel Gauge Assy.
1
49
336713546
Screw M5×10
2
50
336713547
Fuel Gauge Display
1
51
380713553
Fuel Tank Assy.
1
52
336713806
Fuel Filter, Wire Mesh
1
53
336713549
Fuel Cap
1
54
336713807
Tank Fitting With Filter
1
55
336713540
Clamp Ø8×6
7
56
357713580
Hose, Fuel 1
1
57
357713581
Hose, Fuel 2
1
58
336713636
Hose, Fuel 3
1
64
357713535
Axle Pin
2
65
357713592
Wheel
2
66
357713536
Cotter Pin
2
67
380713554
Plastic Front Cover
1
68
380713546
Frame
1
69
336713558
Nut M8
8
70
357713584
Flange Bolt M8×35
2
71
357713550
Wing Nut M6
2
72
357713551
Battery Pressing Bracket
1
73
357713552
Rubber Pad
1
74
357713553
Battery
1
75
357713554
Battery Holder
1
76
336713593
Flange. Bolt M8×45
2
