10
FINGER LOOP
Your T-MAX
™
comes equipped with a Finger Loop
installed in a neutral/straight-forward position. In
order to enhance the ergonomic control of the
T-MAX, it is recommended that the Finger Loop
be slightly offset to better align the thumb with the
control panel.
The Finger Loop can be moved by pushing it to
the desired position.
FINGER LOOP
LOOSEN HERE
INSTALLING FINGER LOOP
A smaller Finger Loop is also provided. In order
to install the smaller Finger Loop, loosen the
threaded connection between the lamp housing
and battery housing until the large Finger Loop is
loosened to a point at which it can be removed.
Insert the collar of the smaller Finger Loop so that
it is seated within the machined groove located at
the top of the battery housing.
IMPORTANT: Ensure that the Finger Loop
remains securely seated during use.
Hand-tighten the connection between
the battery housing and lamp housing as
rmly as possible.
