First Sales OXY2-10 - Component Parts Breakdown & List; System Component Identification; Component Parts List

14
IP05 media is recommended when incoming water pH is less than 7.0 and no manganese is present.
IP05M media is recommended when manganese is present in water supply.
Ref #
Part Number
Description
1
OXY2-10 Vlv Assy W/BP
OXY2-20 Vlv Assy W/BP
Complete Time Clock Control Valve includes
bypass valve
OXY2E-10 Vlv Assy W/BP
OXY2E-20 Vlv Assy W/BP
Complete Electronic Control Valve includes bypass
valve
2
D100S-54
Distributor Tube, 1” x 54”
3
MTP1054N
MTP1354N
Mineral Tank, 10” x 54”, OXY2-10 & OXY2E-10
Mineral Tank, 13” x 54”, OXY2-20 & OXY2E-20
4
IP05
½ cubic foot pail Iron Pro Media Blend
IP05M
½ cubic foot pail Iron Pro Media “M” Blend
5
QC20
20 pounds ¼” x 1/8” gravel
6
JG-38CV
3/8” Check Valve
Component Parts Breakdown & List
6
1
2
3
4
5
