First Sales OXY2-10 - OXY2 Control Valve Parts List; OXY2 Control Valve Parts Details

16
REF #
Part Number
Description
REF #
Part
Number
Description
A
60041SS
Stainless Steel Bypass, 1”
FPT
11
14805
Injector Body Gasket
B
60900-41
Coupling Kit
12
10328
90 Degree Elbow (1/4 Pipe x
3/8 Tube)
C
JG-38CV
Check Valve, 3/8” Tube
13
12092
5.0 gpm DLFC
(OXY2-10)
D
60011-050ASSY
Brine Valve, 1650 Short
Stem, 0.5 BLFC with Tube
12408
7.0 gpm DLFC
(OXY2-20)
Not
Shown
60705-50
5.0 gpm DLFC Housing
(Old Style for OXY2-10)
Not
Shown
12338
Drain Fitting, Hose Barb, 90 Deg
Elbow, 1/2" x 1/2" (Old Style)
60705-70
7.0 gpm DLFC Housing
(Old Style for OXY2-20)
15
19936
Base Seal (2510)
E
60705-50A
5.0 gpm DLFC Elbow
(New Style, OXY2-10)
16
19322
2510 Adapter Base
60705-70A
7.0 gpm DLFC Elbow
(New Style, OXY2-20)
17
19197
Slip Ring
F
60121
Seal and Spacer Kit
18
18303
Tank O-Ring, 2510 Valve
G
60090
Piston Assembly
19
13304
Distributor O-Ring, -121
H
FV2510-1PH
Power Head Assembly,
2510 TC with Cover
20
13030
Distributor Retainer
I
60050-21
Drive Motor Assembly
Not
Shown
40027
J tube for 2510 valve (Old Style)
J
60160-10
Drive Cam Assembly, STF
22
13911
Main Drive Gear
K
60304-13
Timer Assembly, 3200,
12 Day, STF, 120/60
23
18743-1
Timer Motor, 120v/60Hz,
2510/5600 Valve
1
14105
Bypass Valve Seal, Single
Lever
24
15320
Micro Switch, Homing
2
13305
Coupling O-Ring, -019
25
10896
Micro Switch, Step
3
19228-01
Coupling, Adapter
S/ASSY
26
10218
Micro Switch, Drive Motor
4
10692
Injector cover screw
2510 valve
27
10909
Connecting Link Pin
5
11893
Injector Cover
28
10338
Roll Pin
6
14805
Injector Body Gasket
29
12777
Brine Cam, STF
7
10913-2
Injector Nozzle, #2, Blue
30
SCA-926
Environmental Cover
(New Style)
8
10914-2
Injector Throat, #2, Blue
60219-02
Environmental Cover (Old Style)
9
10227
Injector Screen
31
18312
Retainer, Drain
10
17776
Injector Body Plastic
OXY2 Control Valve Parts List
