Copyright 2014 Firstech, LLC. Page 25
CM7000 Master Guide
Alarm and Starter System
techfeed.compustar.com
Pin 1 Black - Negative (-) ground when armed (GWA).
Pin 2 Black/White - 2nd stage negative (-) input. (Instant trigger or arm)
Pin 3 Red - 12V positive (+) output.
Pin 4 Grey/White - 1st stage negative (-) input. (Warn away or disarm)
Option Programming Tables
Option Group 1
Feature Default Setting - I Optional Setting - II Optional Setting - III Optional Setting - IV
1-01
Unlock before, Lock after,
starting
Off On
Lock After Remote
Start Only
Lock After Shutdown
Only
1-02
Lock / Unlock pulse duration 0.8 sec 2.5 sec 0.125 sec 3.5 sec
1-03
Driver's priority unlock Off On
1-04
Double pulse unlock Off Unlock Lock Both Lock and Unlock
1-05
Rearm Output
After Start, Shutdown
and First Lock
After Shutdown and
1st Lock
After Start Only After Shutdown Only
1-06
Reservation Lock
(Manual transmissions)
Locks Before
Reservation Mode is
Set
Hold Start Button for
2.5 sec. to Activate
Reservation Mode
Reservation Sets 10
Seconds After the Last
Door is Closed
Locks After Reservation
Mode is Set
1-07
Unlock / Disarm With Trunk
Release
Unlock, Factory
Disarm, and Trunk
Release
Factory Disarm, Trunk
Release Only
Trunk Release Only
1-08
Passive Mode Off
Passive locking with
Passive Arming
No Passive Locking
with Passive Arming
1-09
Ignition controlled door locks Off On
RPM Locks (Tach
Sensing Mode Only)
1-10
Auto Relock
(If a door is not opened within
this amount of time)
Off 30 sec 60 sec 5 min
1-11
Ignition / Accessory Out
Upon Unlock
Off
Ignition Pulse - same
timing as disarm pulse
Acc Pulse - same
timing as disarm pulse
Ignition and Acc
Pulse - same timing as
disarm pulse
1-12
Arm/Disarm Remote Paging
by iDatalink Module
On Off
1-13
Double Pulse Disarm Single Pulse Double Pulse
1-14
EZGO Off
FT-EZGO Unlock for
FTX
FT-EZGO Unlock
FT-EZGO Lock and
Unlock
1-15
Trunk Output Timing 1 sec 2 sec 3 sec 4 sec
