Special Option Group 1
Feature Setting Value (Seconds)
1 Diesel Timer - DISL 3 ~ 99
2 AUX1 output time 1 ~ 100
3 AUX2 output time 1 ~ 100
4 AUX3 output time 1 ~ 100
5 AUX4 output time 1 ~ 100
6 AUX5 output time 1 ~ 100
7 AUX6 output time 1 ~ 100
8 AUX7 output time 1 ~ 100
FO = Feature Option
1-01 Unlock before, Lock after:
FO1 - Off
FO2 - On: Sends an unlock command as soon as the remote start sequence is triggered then send a
relock command as soon as the CM7 has confirmed remote start success.
FO3 - Lock after start only: Sends a lock command after the CM7 has confirmed remote start
success.
FO4 - Lock after shutdown only: will send a lock command only after the CM7 has successfully
shut down. Note: It will not provide an output if the CM7 is shut down with an
emergency override input. (i.e. hood pin, or foot brake input)
Copyright 2014 Firstech, LLC. Page 28
CM7000 Master Guide
Alarm and Starter System
techfeed.compustar.com
Special Option Group 2
Feature Setting and OP500 Value
Programmable
Output Connector
0 - Default Setting 1~28 – Optional Settings
1 POC #1 (-) Starter Kill (Blue/White)
2nd Light - [1] 2nd Start - [2] 2nd IG1 - [3]
2nd Acc - [4] Status Out - [5] Rearm Out - [6]
Disarm Out - [7] Horn Out - [8] Dome Light - [9]
Aux 1 Out - [10] Aux 2 Out - [11] Aux 3 - [12]
Aux 4 Out - [13] Aux 5 Out - [14] Aux 6 Out - [15]
Aux 7 Out – [16] Defrost - [17] GWA - [18]
Status 2 For Manual Trans. - [19] Siren 2 - [20]
Defrost 2 - [21] VAC - [22] PTS Button - [23]
Aux 3 (EZGO Unlock) - [24] Lock - [25] Unlock - [26]
2nd Unlock (Driver’s Priority) - [27] Trunk Release - [28]
2 POC #2 (-) Auxiliary 1 (White)
3 POC #3 (-) Lock (Blue/Black)
4 POC #4 (-) Unlock (Blue)
5 POC #5 (-) Disarm (Orange/White)
6 POC #6 (-) Rearm (Orange)
7 POC #7 (-) Trunk (Violet/White)
8 POC #8 (-) Status (Black)
