Step 4- Adjusting the lateral support arms.
a) There are two lateral support arms on the Docking Station frame. These are designed
to fix to each side of the cargo area side arches as shown in the images below. The
lateral arm positions can be adjusted by releasing the locking pin, sliding the arm to the
desired position, and placing the locking pin back to secure. The lateral arms have a
simple click release so they will slide out by pushing them and retract by releasing the
button.
