Overview of Quingo Docking Station
The Quingo Docking Station has many parts. It is important that you understand the
location of the parts for reference throughout the handbook and DVD. The diagram
below shows the main parts of the Docking Station.
1 Docking Station
Frame with 4 x
small legs
2 x Outer Rails,
marked L1 for
Left- hand side
and R1 for Right-
hand side
2 x Inner Rails,
marked L2 for Left-
hand side and R2 for
Right-hand side
(image of RH side
inner rail)
4 Long Legs (to
be used when
fitting into a car
that has a deep
cargo area and
not a flat area)
4 Metal
Plates
1 Center Bar to connect rails
R1 and L1 together.
2 Front Support arms
(these connect in to R1
and L1 once R1 and
L1 are fitted to the
frame.)
