MODEL MODEL F TAPE ATTACHMENT ASSEMBLY
Plate "J"
ITEM
QUAN.
PART NO.
DESCRIPTION
1 1 A1608 Bracket, Holder Reel
2 1 A1609 Shaft, Holder Reel
3 2 F103212 Screw, Flat HD - #10-32 x 1/2
4 2 B83238 Screw, BDNG. HD - #8-32 x 5/16
5 1 A1612 Button, Reel Holder
6 1 A1611 Spring
7 1 A1610 Form, Wire
8 1 B1623 Reel, Holder (Complete)
9 1 A1627 Bracket, Knife Mount
10 1 F63214 Screw, Flat HD - #8-32 x 1/4
11 2 SF83258 Screw, Soc. Flat - #8-32 x 5/8 BO
12 1 NH1428 Nut, Hex - 1/4-28 UNF
13 1 F63212 Screw, Flat HD - #6-32 x 1/2
14 1 SF83278 Screw, Soc. Flat - #8-32 x 7/8 BO
15 1 A1602 Blade, Stationary
16 1 A1603 Stud, Spring Holder
17 1 A1607 Spring, Extension
18 1 B1626 Assembly, Blade and Handle
19 1 P1606 Knob, Plastic
20 1 P142834 Screw, Pan HD - 1/4-28 x 3/4
21 1 WL14H Washer, Lock - 1/4 Heavy
22 1 B1633 Assembly, Knife (Complete)
23 4 SB832316 Screw, Soc Bttn #8-32 x 3/16 BO
24 1 A1616 Weldment, Folder - Front
25 1 A1614 Guide, Tee-Male
26 1 A1615 Guide, Tee-Female
27 1 B1613 Support, Back Folder
28 2 B832716 Screw, BDNG. HD - #8-32 x 7/16
29 1 A1617 Weldment, Folder - Rear
30 1 B1624 Folder, Complete
31 1 SF83258 Screw, Soc Flat 8-32 x 5/8
(optional screw for Model F ONLY)
TAPE ATTACHMENT ASSMEBLY #1650 REQUIRES:
1 11212 PLATE, THROAT (TAPE)
1 11399 ASSY, PRESSER FOOT (TAPING & PLSTC)
