Panda xControl
29.9.16 Chapter 2: Panda xControl - Page 21
Fig. 2.5.2.11-1: Sub-menu: Optional Measurement DataThe desired optional measurement data is changed by using
the "Step-up"/"Step-down" keys and the setting is confirmed
with the "Start/Stop - Enter“ key.
The desired option is selected by using the "Step-up"/"Step-
down" keys and the setting is confirmed with the "Start/Stop -
Enter“ key.
The "Back" item returns you to the Panel sub-menu.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.12 Resetting all values of the Panel sub-menu to default values
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.
Fig. 2.5.2.12-1: Resetting all values"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.13 Return to Main Menu
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.
2.5.3 Sub-menu: "Generator"
Fig. 2.5.3-1: Generator Sub-MenuThe following items can be selected in the Generator
sub-menu:
1. Autostart
- configuring the Autostart function
2. Optional DC Output
- setting the optional DC output
3. Switch Outputs
- manual switching of the individual digital outputs
4. Event Memory
- displaying the event memory
5. Display System Devices
- displaying the detected system devices
6. Reset to standard
- all parameters of the "Generator" sub-menu are reset to
