2.6.2.2 Description of the symbols
Fig. 2.6-1: Description of the symbols
82 Stop solenoid - Pull Failure stop solenoid pull coil Short circuit yes n.a.
83 Optional DC out Failure optional DC out Short circuit yes n.a.
84 Power Supply Current Sensor Current too
high
Short circuit defect yes yes
85 Boost Relay Failure Boost relay short circuit or too many
modules
yes yes
86 Bus Power Bus Power Consumption high Short circuit yes no
89 Battery voltage Battery voltage too high yes yes
93 Power out relay Failure power out relay Short circuit or defect yes yes
94 AC Voltage L2 Voltage too high L2 yes yes
95 AC Frequency L2 Frequency too high L2 yes yes
96 AC Current L2 Current too high L2 yes n.a.
97 AC Power L2 Power too high L2 yes n.a.
98 AC Voltage L3 Voltage too high L3 yes yes
99 AC Frequency L3 Frequency too high L3 yes yes
100 AC Current L3 Current too high L3 yes n.a.
101 AC Power L3 Power too high L3 yes n.a.
126 Temperature Fuel Fuel Temperature too high yes n.a.
130 No Panel found Wrong patch cable/wrong
contact
check cable/harness n.a. yes n.a.
131 Communication FP
BUS
Communication failure lost communication with Panel n.a. yes
132 Service interval Service due yes n.a.
133 BUS Module lost (3ph-
measurement)
yes n.a.
134 BUS Module lost (DC-
measurement)
n.a. yes
135 Sync failure generators cannot be synced second generator cannot be
switched to the running
generator
yes
136 Communication motor
controller
No data from motor controller Short circuit defect yes
137 Air filter Error Air filter Bad air filter yes
139 Sync module No data from sync module Short circuit defect yes
140 load balancing Generator takes less load Generator produces
insufficient power
yes
141 Configuration sync
module
Sync module available but not
selected
Crippled mode only no
246 Service done user Service interval reset n.a. n.a. yes
251 Admin Param changed user Parameter changed at Admin
level
n.a. n.a. yes
255 Reserved n.a. n.a. yes
Symbol Description Symbol Description
WARNING Current Generator output
Error shutdown Frequency Generator output
No. Description Cause Explanation Warning Gen.Stop Info
