Parts No. Image Pc. Description Number
1
Frame support
1
2
Proledwheelguide
2
3
6 x 14 Screw
4
4
Ø 6 x 18 Washer
12
5
6Ma Self-lockingnut
4
6
Protective caps
2
7
Turning handle
6
8
Support plate
1
9
U-bolt
3
10
Safetybelts
For fastening the wheel
3
11
Ø 6 x 12 Washer
2
