FISCHER 18093 - Assembly: Connecting Wheel Guides; Assembly: Mounting Frame Support

11
GB
Step 1
Connecting the profiled wheel guides
(Part no. 2)
The following parts are required for this
assemblystep.
Connectbothprofiledwheelguidesby
layingoneovertheotherasdepictedinthe
illustrationandtheninsertingthemonebyone
intothemountinghole.Fastensecurely(tool
not included). Then attach the protective caps
to the wheel guides (parts no. 6).
Step 2
Mounting the frame support
(parts no. 1) on the previously
assembled profiled wheel guides
The following parts are required for this
assemblystep.
CAUTION:Beforethisstep,checkthe
dimensionsandformofyourbiketomake
surethattheframeiscorrectlyandsecurely
installed.Attachthepreassembledprofiled
wheelguidesinapositionthatfitsyourbike,
oneaftertheother.Fastensecurely(tool
notincluded).Yourbikerackisnowfully
assembled.
3
4
4
5
6
6
2
2
1
3
4
11
5
Parts No. Image Number
2
2
3
2
4
Ø 6 x 14
4
5
6Ma
2
6
2
Parts No. Image Number
1
1
3
2
4
Ø 6 x 14
2
5
6Ma
2
11
Ø 6 x 12
2
Ill. 1 Ill. 2
5. Assembly
